  • Optic cables
  • Fire Resistant
  • FSC 180

Distribution FSC 180

Armoured

Indoor

Outdoor

Halogen Free

Fire Resistant

Datacenter

Duct

1
2
3
4
5
6
1

FRNC buffered optical fibre

2

Waterblocking E-glass yarn

3

Ripcord

4

FR-LSZH inner jacket, UV stable

5

Corrugated steel tape

6

FR-LSZH outer jacket, UV stable

This cable is suitable for indoor or outdoor installation. The cable is fire resistant. The cable has full rodent protection. Passed following tests for circuit integrity: IEC 60331-11-1 and IEC 60331-25-1.

Design
Code
Max. fiber
count
Loose tube
diameter
[mm]
Cable sizeNet weight
[kg/km]
Max. load
(installation)
[N]
Crush
Resistance
[N/10 cm]
Z2852417.5332.03,0008,000

Temperature range

Installation: -15 to +50 °C | Operation: -20 to +80 °C | Storage: -20 to +80 °C
