Improved
Indoor
Halogen Free
FTTx
High Tensile
Datacenter
Temperature range - 42X8
Installation: -5 to +50 °C | Operation: -20 to +60 °C | Storage: -20 to +60 °C
| Design Code | Max. fiber count | Simplex diameter [mm] | Cable outer diameter [mm] | Net weight [kg/km] | Max. load (installation) [N] | Crush Resistance [N/10 cm] |
|---|---|---|---|---|---|---|
| 42×8 | 24 | 2.0 | 15.4 | 246.0 | 4,500 | 2,000 |
| 44×8 | 24 | 2.4 | 18.1 | 334.0 | 5,500 | 2,000 |
Temperature range - 44X8
Installation: -5 to +40 °C | Operation: -5 to +50 °C | Storage: -25 to +60 °C
